Oil Melting Point Instrument Series
Automatic oil automatic precise measuring instrument for melting various oil product melting points, good navigation mechanical grease instrument of melting the perfect combination of high precision Peltier temperature control technology and high-definition video camera technology, not only provides the test result is accurate, stable, and reliable for users, but also bring the test experience efficient and convenient for users. Peltier temperature control technology can realize high precision temperature control,high-definition video can conveniently and clearly see the whole process of sample melting, automatic detection to eliminate the subjective error to determine the melting point, reducing the labor intensity of the staff, convenience for the user to measure the melting point of the sample accurately.
The Main Technical Indicators of JHY30 & JHY50
| Model | JHY30 | JHY50 |
| Temperature control range | RT-100℃ | 6-100℃ |
| Detection method | Semi-automatic | Semi-automatic |
| Capacity per batch | 2pc./batch | 2pc./batch |
| Temperature resolution | 0.1℃ | 0.1℃ |
| Temperature gradients | (0.1-10.0)℃/Min | (0.1-10.0)℃/Min |
| Temperature accuracy | ±0.3℃ | ±0.3℃ |
| Repeatability | 0.1℃/Min时±0.1℃ | 0.1℃/Min时±0.1℃ |
| Camera&Video | Camera | Camera&Video |
| Video playback | — | YES |
| Operator account | — | 8 |
| Result storage | 200 | 400 |
| SD card capacity | 8G | 8G |
| Display | TFT Touch screen | TFT Touch screen |
| Interface | USB RS232 SD card Enternet | USB RS232 SD card Enternet |
| Opening capillary size | I.D>1.0mm,O.D.1.4mm | I.D>1.0mm,O.D.1.4mm |
| Double opening | Double opening | |
| Power | 110-220V 50/60HZ 120W | 110-220V 50/60HZ 120W |
1: Paltier precise temperature function;
2: a key automatic detection function;
3: in line with the international and ISO in the determination of the melting point of oils and fats.
The Main Technical Indicators of JHY70 & JHY90
| Model | JHY70 | JHY90 |
| Temperature control range | RT-100℃ | 4-100° |
| Detection method | Fully automatic(compatible with Semi-automatic) | Fully automatic(compatible with Semi-automatic) |
| Capacity per batch | 2pc./batch | 2pc./batch |
| Temperature resolution | 0.1℃ | 0.1℃ |
| Temperature gradients | (0.1-10.0)℃/Min | (0.1-10.0)℃/Min |
| Temperature accuracy | ±0.3℃ | ±0.3℃ |
| Repeatability | 0.1℃/Min时±0.1℃ | 0.1℃/Min时±0.1℃ |
| Camera&Video | Camera | Camera&Video |
| Video playback | NO | YES |
| Operator account | 10 | 20 |
| Result storage | 600 | 1000 |
| SD card capacity | 8G | 16G |
| Display | TFT Touch screen | TFT Touch screen |
| Interface | USB RS232 SD card Enternet | USB RS232 SD card Enternet |
| Opening capillary size | I.D.1.0mm,O.D.1.4mm | I.D.1.0mm,O.D.1.4mm |
| Power | 110-220V 50/60HZ 120W | 110-220V 50/60HZ 120W |
Standard:SNT0801.5-2015、GB/T24892-2010、GBT12766-2008
Use filed
Chemical, pharmaceutical, supervision, food and drug administration, and quarantine, are widely applied in colleges and universities and other related departments. Melting point is an important feature of the material, material research is of great significance. Is the production of medicines, spices, dye, and other organic crystal substances essential equipment.
