Shaking Incubator
What is Shaking Incubator?
The shaking incubator is a special constant temperature culture device for the cultivation and breeding of molds and microorganisms. It is especially suitable for scientific research and production in the fields of bioengineering, chemical engineering, medical research, agriculture and forestry sciences, aquatic products, animal husbandry, and environmental protection.
Features of the Shaking Incubator
- Integrated with incubator and shaker to save space and cost with tempered glass window.
- ABS shell, stainless steel chamber.
- Large LCD display to display temperature and shaking velocity.
- With easy operations of storage function of working parameters.
- Auto-recovery after power interruption as originally programmed.
- Auto-stop protection to keep the sample safe when the door is opened. Strong air spring rod with easy opening and closing.
- Brushless DC motor, more stable and reliable.
- Equipped with leakage protection.
Specifications of the Shaking Incubator
| Model | DW-SI-103B | DW-SI-100B | DW-SI-200B |
| Shaking Speed | 20-300rpm | ||
| Shaking Accuracy | ±1rpm | ||
| Swing Amplitude | φ26mm | ||
| Standard Configuration for Flasks | 100ml×9 | 50ml×4, 100ml×4, 250ml×3, 500ml×3 | 50ml×5, 100ml×5, 250ml×5, 500ml×3 |
| Max. Volume | 50ml×12,100ml×9 | 50ml×20,100ml×16,250ml×12,500ml×9 | 50ml×5,100ml×5,250ml×4,500ml×12 |
| Tray Size (mm) | 295×245 | 450×370 | 450×410 |
| Timing Range | 1~9999min | ||
| Temperature Range | RT+5~60℃ (RT:25℃) | RT+5~60℃ | 4~60℃ (Cooling) |
| Outer Size (cm) | 44×41×39 | 60×58×51 | 78×68×56 |
| Package Size (cm) | 58×53×54 | 74×70×66 | 92×80×61 |
| N.W (kg) | 31 | 72 | 100 |
| Chamber Volume (L) | 20 | 48 | 70 |
| Power Rating | 220W | 320W | 580W |
| Power Supply | AC 220~240V, 50~60Hz | ||
Shaking Incubator Display
