DW-52 Series of Water Bath Rotary Evaporator
Features of DW-52 Series of Water Bath Rotary Evaporator
- Main metal parts are made of stainless steel and rust-proof aluminium alloy.
- Elegant appearance with compact structure design.
- Practical and durable to use.
- The sealing system is made of fluoro rubber and imported PTFE material; combined with glass spindle, which is durable and without slag droppings.
- Water bath with a temperature range from room temperature to 99 ℃.
- Protection function: heater stop heating in over-temperature condition.
Technical Parameter of DW-52 Series of Water Bath Rotary Evaporator
| Model | DW-52CS | DW-52CS-1 | DW-5203 |
| Lift | Manual sliding lifting with length of 150mm | Rotary lifting with lifting length of 150mm | Strut-press lifting with length of 150mm |
| Rotating Speed | 0-150rpm/min | 0-130rpm/min; | |
| Rotation control | Rotary stepless control | stepless control; digital display | |
| Evap. Capacity | / | Max.0.18L/min (H2O） | Max.0.21L/min (H2O） |
| Temp. range/precision | Auto control; digital display; Water Bath：RT.-99℃±1℃ | ||
| Bath Material | Integral Teflon bath | stainless steel heating bath with outer heater | |
| Bath Size | Φ22*11.5cm | Φ24.5*15cm | Φ26*15cm |
| Vacuum | NO | NO | NO |
| Heater Power | 1KW | ||
| Flask Volume | 0.25-2L | 0.25-3L | |
| Environment Temp. | 5-40℃ | ||
| Condenser | Cold trap | Vertical Dual-reflux coil condenser | |
| Condense area | / | 0.15㎡ | 0.31㎡ |
| Feeder | Valve type feeding pipe equipped with tetrafluoroethylene pipe and water retaining ring | ||
| Sealing | Imported PTFE and special complex compounded with special technique, which ensures good sealing and improves the anti-corrosion and durability property. | ||
| Factory Configuration | 24# eggplant Rotating Flask 500ml*1 Ball mill mouth Receiving Flask:250L*1 |
24# standard mouth Rotating Flask 3L*1 Receiving Flask:2L*1 |
24# standard mouth Rotating Flask 3L*1 Receiving Flask:2L*1 |
| Input | AC220V/50HZ | ||
| Size&Weight | Pack size: 49*37*58cm; G/W 20KG Product size: 71*31*91cm |
Pack size: 69*46*42cm+43*37*32cm; G/W 23+6KG Product size: 79*40*83cm |
Pack size: 77*51*47cm+43*37*32cm; G/W 25+6KG Product size: 79*45*86cm |
